High-Production Two-Stations Automatic Polishing Machine,Used In Metal Surfacement Polishing.
Product Description:
The Automatic Polishing Machine is an advanced polishing equipment that offers exceptional performance for various polishing processes.
Technical Parameters:
| Parameter | Value |
| Dimensions(L*W*H) | 3000*3100*2900mm |
| Machine Power | 17KW |
| Rated Voltage | 380V |
| Max.Diameter of polishing wheel | 600mm |
| Min.Diameter of polishing wheel | 400mm |
| X-Axis travel (mm) | 1100 |
| Y-Axis travel(mm) | 900 |
| Z-Axis travel(mm) | 700 |
| U-Axis travel(mm) | ±60° |
| V-Axis travel(mm) | ±360° |
| W-Axis travel(mm) | ±360° |
| Max. Speed X axis | 20m/min |
| Max. Speed Y axis | 20m/min |
| Max. Speed Z axis | 20m/min |
| Max. Speed U axis | 30°/sec |
| Max. Speed V axis | 30°/sec |
| Max. Speed W axis | 30°/sec |
Applications:
The Automatic Polishing Machine from the brand DZ (Model Number: NC62) is designed for industrial polishing tasks. It is made in CHINA and certified with CE ISO standard. The maximum diameter of polishing wheel is 600mm, while the W-axis max. speed can reach 30°/sec.. The X-axis travel can reach 1100mm, and the machine power is up to 17KW. The U-axis travel is ±60℃, which makes it an ideal surface finishing device.
Packing and Shipping:
Packaging and Shipping of Automatic Polishing Machine
The Automatic Polishing Machine is packaged using industry-standard packaging and shipping materials to ensure the product arrives in good condition. All boxes are shipped with a tracking number for traceability purposes. The following items are included with the Automatic Polishing Machine shipment:
- Automatic Polishing Machine
- Instructions for setup and operation
- Power cable or adapter, if applicable
- Any additional accessories, if applicable
The Automatic Polishing Machine is shipped in one package. If the order includes additional accessories, they are shipped in separate packages. The packages are shipped via the selected carrier's ground service. We do not offer expedited shipping options.
FAQ:
- Q: What is the brand & model number of this Automatic Polishing Machine?
- A: The brand & model number of this Automatic Polishing Machine is DZ NC62.
- Q: Where is this Automatic Polishing Machine made?
- A: This Automatic Polishing Machine is made in China.
- Q: Does this Automatic Polishing Machine have certifications?
- A: Yes, this Automatic Polishing Machine has CE and ISO certifications.
- Q: What is the purpose of this Automatic Polishing Machine?
- A: This Automatic Polishing Machine is used for polishing products.
- Q: What is the size of the Automatic Polishing Machine?
- A: The size of the Automatic Polishing Machine depends on the model.
